Optos California Optomap Color

Description

Optos California Optomap Color

Optos California Optomap Color has incorporated new hardware and software technology enabling practitioners to see more, discover more and effectively treat more ocular pathology thus promoting patient health. California’s innovative optical design provides high resolution images showing fine detail whether viewing the entire retina or zoomed in to inspect macula, optic nerve head, or small pathology.

Specifications

Image Modalities: optomap color and optomap plus (red and green laser):
Color composite view
Green laser view
Red laser view
optomap af (green laser): autofluorescence
Resolution: optomap color: 20 μm, optomap plus, af : 14 μm
Wavelengths: Red laser: 635 nm, Green laser: 532 nm
Exposure Time: Less than 0.4 seconds
Foot Print: Width: 550 mm / 22 inches
Depth: 550 mm / 22 inches including chinrest
Height: 608-632 mm / 24-25 inches
Weight: 75 lbs
Communication Protocol: DICOM Compatible

Image Modalities

Color rg
Color rgb (available with rg/af/fa combined model)
Sensory Red-free
Choroidal
Autofluorescence (green and blue*)(*feature may not be available in all regions)
Fluorescein angiography
Indocyanine green angiography

Views

Standard: 200⁰ Single Shot
Auto-montage: Up to 220⁰ (not available for fa or icg)
Central Pole: Detailed view of the macula
Stereo: Image pairing for optic disc and retinal evaluation
4-in-1 Color Depth Imaging

In addition to a field of view of 200° or 82% of retina in a single shot, California, offers the following benefits:

Visibility of 50% more of the retina when compared to other conventional imaging devices
Motorized head and chin rest to more easily align those patients who require additional assistance during imaging
4-in-1 Color Depth Imaging™ produces optomap color rgb, optomap color rg, optomap Sensory Retina and optomap Choroidal in a single shot.
Dye-based imaging modalities fa and icg as well as interweaved angiography for parallel capture of fa and icg images without manually switching between imaging modalities

Optos ultra-widefield technology produces a single 200 degree capture in less than half a second. The California device is available in three models with six imaging modalities to meet the needs of every practice: colour, sensory (red free), choroidal, autofluorescence with green laser (af), fluorescein angiography (fa), and indocyanine green angiography (icg).
