Carl Zeiss Cirrus 6000 OCT Imaging System

Description

Carl Zeiss Cirrus 6000 OCT Imaging System

Carl Zeiss Cirrus 6000 OCT Imaging System is all about its speed. With increased speed comes greatly improved resolution and detail on cube, raster and OCTA scans, and the new faster CIRRUS enables me to incorporate these more reliable scans into daily workflow and make important treatment decisions for patients.

Features

High-Speed Imaging: 100,000 A-scans per second, with OCT cube scans completed in 0.4 seconds.
Wide Field of View: Large scan areas up to 12×12 mm for a comprehensive retinal view.
Enhanced Microvascular Detail: HD AngioPlex scans with 8×8 and 6×6 mm field sizes.
Proven Analytics: Clinically-validated tools for retina, glaucoma, and anterior segment analysis.
Seamless Data Transfer: Compatibility with previous CIRRUS models for continuity of care.
Motion Artifact Reduction: FastTrac eye tracking technology ensures crisp, detailed images.

Performance OCT
Faster imaging with greater detail, at 100,000 scans per second, for improved patient care.

Proven analytics
Comprehensive, clinicallyvalidated tools to diagnose and manage a range of conditions.

Patient-first design
Seamless transfer of raw patient data from previous generations of CIRRUS for continuity of patient care.

Faster imaging

Reduce chair time and speed up your practice.
270% faster OCT scans and 43% faster OCTA scans.
OCT cube scans in as little as 0.4 seconds.
High-speed imaging in combination with FastTrac eye tracking technology reduces the chance of motion artifacts such as those caused by blinks and saccades.

Greater detail

View more in seconds and dig deeper with high-definition imaging.
12×12 mm single-shot OCTA cube scan in addition to 8×8, 6×6 and 3×3 mm scans.
High-Definition AngioPlex scans (8×8 and 6×6 mm) for even greater microvascular detail without limiting the field of view.
2.9 mm scan depth.

Faster, wider with a new level of detail

At 100,000 scans per second, ZEISS CIRRUS 6000 enables clinicians to image a larger field of view up to 12mm in a single scan. It also captures high-definition (HD) OCT and OCT Angiography (OCTA) scans, revealing the finer microvascular details of the retina and providing more insight into your patient’s condition.

Multi-layer segmentation

Quantifiable AngioPlex Metrix, Improved layer visualization, Seven-layer segmentation
Inner Limiting Membrane
Retina Nerve Fiber Layer
Inner Plexiform Layer
Inner Nuclear Layer
Outer Plexiform Layer
IS/OS Junction
Retinal Pigment Epithelium

AngioPlex Metrix OCTA Quantification

AngioPlex Metrix for Macula and ONH
AngioPlex Metrix allows clinicians to objectively assess and track progressive eye diseases such as diabetic retinopathy and glaucoma with quantification tools such as Vessel Density, Perfusion Density, and Foveal Avascular Zone (FAZ) for the macula, and Capillary Flux Index for the optic nerve head.
